New Type D & E of Inkcore Board of Videojet Small Character Inkjet Printers

There are mainly three types of inkcore board for Videojet small character inkjet printers, type A B & C.

Now we have two new types of inkcore boards, type D & E.

As we look closely at these 5 types of inkcore boards, we can find type A B & C look very much similar, the differences lies on the bottom right part, type A inkcore board doesn’t have any square black dot, type B got 12 ones, while type C have 6 black dots line up in “L” shape.

Type D & E are slimmer than type A B C, these two look similar two, the only difference lies on the middle right part, the 3 little electronic gadgets on type E are bigger.

Despite all these surface difference, the fundamental differences among the Videojet inkcore boards are the program inside the PCB. And one very import thing to bear in mind, every Videojet CIJ printer, such as 1210, 1220, 1510, 1520, 1610, 1620 etc, they can have inkcore board from A to E type, please do take a picture, or be specific of which type(A/B/C/D/E) are you looking for.

Here is a example of we deliver a compatible 1210 type A inkcore board to our customer, which is the most common type, but it turns out customer actually look for a type C inkcore board. So without any delay, we deliver the type C inkcore board to our customer asap. Though both of us share 50/50 responsibility, we cover all the fees for we could prevent this happening, if we gives a heads-up to custom in advance. It’s a lesson to learn, do figure out which type of Videojet inkcore board you are looking for, or else it will be a waste of time & money.

Two Types of Markem Imaje 9040 Print Head

Markem Imaje 9040 got two types of print heads, one with single jet, the other one with bi/twin jet. Let’s see how these two print heads differ from each other.

The part number of Imaje 9040 single jet print head is ENM35370, print module(9040-1G-L=3 meter). 1.1G means it’s with single jet nozzle, printing effect up to 4-line per time, umbilical 3 meters long.

The part number of Imaje 9040 bi/twin jet print head is ENM35372, print module(9040-1.2G-L=3 meter). 1.2G stands for bi/twin jet, it can print up to 8 lines per time.

Also ENM53370 & ENM35372 are for standard black ink printer 9040 model only, they are not compatible with 9040 Contrast model, which applies white pigment.

Markem Imaje Refurbished ENR36868 9040 Contrast Print Head

Here we are going to clarify a little bit that refurbished Markem Imajeprint head for standard black ink, does not compatible with white pigment printer. That is because the structure of white pigment is far more complicated than standard black ink, which is thicker and powder-ish. If you keep the white pigment still for a while, you will see there are three layers, on top is oily material, the middle one looks like just liquid, the bottom one is heavy white powder, while in standard black ink you will not see such layers.

So when the Imaje Contrast printer is on, it takes extra effort for the pumps & print heads to work with the sticky, powder-ish consumable. What will happen if we insist to install the spare parts for 9040 on a 9040 Contrast? Well for starter, the spare parts work fine for a few days, or weeks, then it will stop working, for the white pigment working situation is more than the parts can bear anymore. For Markem Imaje pumps, print heads, please tell us if they are applied on standard black ink printer such as 9040, 9450 etc, or on the colored pigment Contrast model.

What If the White Pigment Markem Imaje Shows No Pressure

As white pigment is stickier & with large particles than standard black ink, it easily causes the pressure pump stuck & therefore 0 pressure faulty notice pops up.

When we come across this situation, no worries, take a deep breath & let’s fix it. Chances are the pump is stuck, we just need to soak the white pigment pressure pump in cleaning solution and clean it up. If you want to have a thorough clean, say open the pump to have a deeper cleaning, please do remember don’t screw the screws too tight or too loose when you assemble the pump back. The three pieces of M3 screw torque should be 14kgfcm. If the screws are too tight, the pump will lock itself & stop working at all; if it’s too loose, ink will leak.

Don’t Forget to Install the Connector on Your Videojet Ink Core

One of my clients complains that the refurbished Videojet ink core he bought from me was broken, and the ink was spitting. So I ask him to send me a picture of how the Videojet ink core was leaking, that we can see if we could offer guidance to repair on site.

From the picture, we notice that there is a missing part, which is vital for the leakage because it contains sealing ring in it. This is the connector for Videojet 1000 series ink core, which perfectly covers the circled area.

After replacing the Videojet ink core, please don’t forget to install this part, it’s small but important.

Apart from forgetting to install the sealing part, there is another reason that may lead to ink leakage, the leakage in tube, which takes more work to fix it. We need to recycle the good tubes from old ink core, and then apply them on the replacement. Please check on below videos of how to recycle the tubes.

Any questions, please feel free to contact us.

Why My ENM5675 Is More Expensive

You may notice that the price of compatible ENM5675 Cannon Holder in our store is higher than other suppliers. Well, don’t jump to the conclusion that we over charge you right away, in fact, if you look close at our product picture, you will find where lies the price gap.

First, the most obvious difference in our ENM5675 is that it’s a kit, not just a Cannon Holder, which comes with a small screw driver, same as the original Markem Imaje ENM5675. Besides, the small screw accessories are made of metal, instead of fragile plastic. It provides extra strength for the holder.

So are we clear now? Any questions, please feel free to contact us.

I just want this Imaje Surface Plate?

“My client sends me this picture, so I want the exact same Imaje surface plate “. Ok, no problem, if you want the longer type of Imaje surface plate, you got the long type surface plate, but they actually work the same.

These two types of compatible Markem Imaje surface plate are actually same, with same function and same price, but with different appearance. If you have been installing the shorter type and find it suits you, or if your client insists nothing change, order the same long type plate as usual, either way will be fine. We have sufficient stock for both Imaje surface plates.

For further inquiry about this surface plate, please fill in below contact form, we will reply you asap.
